| SJ50/55/60/65/75H 高速雙螺桿ABA 型PE吹膜機 |
| 類別: 吹膜機 |
| 電話: 0577-66817170 |
| 手機: 15858567170 |
| Email: [email protected] |
| 浙江省瑞安市東山經濟開發區 |
1.用途
用于吹制高低壓聚乙烯，產品廣泛用于復合膜，包裝膜，農業復蓋膜，紡織品，服裝袋或膜等包裝；主電機采
用變頻調速，增加了主機調速的穩定性，并可節電30%，螺桿料筒采用38鉻鉬鋁，經氮化處理，牽引機架采用
升隆式，不管吹大、小規格薄膜均能使其冷卻效果達到最佳。
2. 主要技術參數Main technical specification
|
Model |
SJ45/50-800H |
SJ50/55-1000H |
|
Suitable material |
HDPE or LDPE, LLDPE |
HDPE or LDPE, LLDPE |
|
Screw diameter |
45mm×1set;50mm×1set; |
45mm×1set;50mm×1set; |
|
Screw L/D ratio |
28:1 |
28:1 |
|
Film max. Width |
800mm |
1000mm |
|
Film thickness |
0.009-0.15mm |
0.009-0.15mm |
|
Max. Output capacity |
80-100KG/H |
100-120KG/H |
|
Average power consumption |
55kw |
70kw |
|
Gross weight |
2800KGS |
2800KGS |
|
Dimension |
5200×2800×6500mm |
5500×3000×7500mm |
|
Power condition |
380V, 50Hz, 3 phase |
380V, 50Hz, 3 phase |
-
